- Features
- Specifications
- Compliance with DIN/ISO 4788.
- With individual Class ‘A’ Certificate.
- Printed in Blue.
- Highly resistant to chemical attack.
- Calibrated at 27°C.
| Hydocs Cat | Capacity (mL) | Diameter (mm) | Height (mm) | Tolerance (mL) | Graduation Intervals (mL) | Quantity |
| HY3201-05 | 5 | 13.7 | 115 | ± 0.05 | 0.1 | 2 |
| HY3201-10 | 10 | 15.3 | 140 | ± 0.10 | 0.2 | 2 |
| HY3201-25 | 25 | 21.45 | 170 | ± 0.25 | 0.5 | 2 |
| HY3201-50 | 50 | 25.25 | 200 | ± 0.50 | 1 | 2 |
| HY3201-100 | 100 | 29.2 | 260 | ± 0.50 | 1 | 2 |
| HY3201-250 | 250 | 38.9 | 335 | ± 1.00 | 2 | 2 |
| HY3201-500 | 500 | 53.35 | 365 | ± 2.50 | 5 | 2 |
| HY3201-1L | 1000 | 65.4 | 465 | ± 5.00 | 10 | 2 |
| HY3201-2L | 2000 | 85 | 505 | ± 10.00 | 20 | 1 |
